The Bioteknix BG-100 Heavy Duty Boom Barrier is engineered for demanding environments requiring robust, high-performance vehicle access control. Ideal for industrial zones, logistic parks, toll plazas, and large commercial premises, this heavy-duty model is built to handle continuous, high-volume operation. It supports boom arms up to 6 meters and features adjustable opening/closing speeds from 1 to 6 seconds. Powered by a high-torque brushless DC motor, the BG-100 Heavy Duty offers smooth, reliable, and low-maintenance operation. Its reinforced, weather-resistant housing ensures durability in extreme conditions. Advanced safety features include anti-crush sensors and auto-reverse technology. Fully compatible with RFID, ANPR, and remote access systems, the Bioteknix BG-100 Heavy Duty is the ideal choice for secure, efficient, and long-term vehicle access control in the toughest environments.
| Maximum length of Boom | 6m |
| Boom Rest Stand | Yes |
| Arm material | Aluminum |
| Time for Up/down | 6s |
| Input control signal | Dry contact |
| Ingress protection Degree | IP54 |
| Input Interface for | * Photocell * Air switch * Loop detector |
| Output interface | lamp |
| Optional Interface | Access control panel, Standalone access control,Control button |
| Remote control | Yes,upto 25 meters |
| Mode | Automatic/Manual |
| Incorporated control panel with 3 push buttons (STOP/UP/Down) to control the motor Bumping bounce back | Optional |
| Auto closing time | 1-80s |
| SMPS - Input | AC 220V / 110V, 50Hz / 60Hz |
| Motor power | 90W, 220V AC |
| Dimension (mm) | 268 X 348 X 1050 | operating temperature | -20˚C ~ +50˚C |
| Features | *Can control by three position switch or by remote control unit, operate ‘OPEN’, ‘CLOSE’ and ‘STOP’ * Machine core with compression spring, effectively avoids the accidents caused by spring breaking. * Motor cooling fan, solving the problem of heat-protection. * Double safety limit switches (Optional) * Auto Close function. * Manual Release * Duty Cycle 100% * Support the external and internal Loop Detector (Optional) * Traffic Light interface. (Optional) * Wire control (switch signal)\ Remote control ( upto25m) * Compatible with Weigand and RFID Readers * Compatible with bio-metric * Die-casting aluminum alloy motor, precision and good at thermal radiating * Support the infrared photocell for anti-bumping function (optional) |
