D468-6

6 ZONE SINGLE DOOR PANEL WALK THROUGH METAL DETECTOR

The Bioteknix D468-6 is a high-performance 6-zone walk-through metal detector featuring a compact single door panel design. Ideal for areas with limited space, it offers precise multi-zone detection to accurately locate metallic threats. Designed for high-traffic environments, the D468-6 provides adjustable sensitivity, clear LED zone indicators, and a user-friendly control panel for quick configuration. Built with durable, tamper-resistant materials, it ensures reliable performance in schools, airports, government buildings, and event venues. With fast screening capability and easy installation, the Bioteknix D468-6 enhances your security setup without compromising efficiency or space. Suitable for indoor or sheltered outdoor use.

Datasheet

share the website to

parameters

Working principle Electromagnetic
Materials ABS (Acrylonitrile Butadiene styrene) raw materials
Frequencies 0-99
Net weight 19 KG
Gross weight 24 KG
External size 2203x580x117mm
Passage size 2007x720x446mm
Detection Ferrous metals < 75gm
Distance between person and door <= 30cm
Working humidity 99%, non-condensing
Working temperature -20°C-65°C
Input AC 100 V-240 V/ Frequency 50HZ-60HZ
Product colour Matte Black
IP rating IP54
Sensitivity adjustable 0 - 400
Volume adjustable 0 - 50
Alarm volume 0 - 3 sec
Alarm tones 15 different tone
Detection of metal Thickness 2mm, length 50mm, Width 20mm Detection of metal on dual side distance of 600mm
Features * Support Multi Zones by selecting 3/6 Zones
* The sensitivity of the Door can be adjusted between specific doors Right/Left* Reset of Counts* Manual Calibration
* 5 Digit7 Segment Bright Digital LED display* Integration of Entrance Automation Devices(Turnstile, Flap /Swing Barrier) through Access Controller of IOT board that blocks person with any Prohibited Items (Optional)
* Has a low Magnetic Field Technology
* Ergonomic structure new design
* High bright new LED digital with zones display
* Easy fixing of cross beams with side door DFMD controller
* Helps in detection of prohibited items
* Infrared sensor for pass count & alarm count
* With a dual-sided detection distance of 60cm
* LED Indication on both sides of the door
