HM300

HAND HELD METAL DETECTOR

The Bioteknix HM300 is a high-sensitivity handheld metal detector designed for quick and efficient security screening. Lightweight, ergonomic, and easy to operate, the HM300 detects concealed metallic objects with precision, making it ideal for security personnel at airports, schools, public events, correctional facilities, and checkpoints. It features adjustable sensitivity levels, fast response time, and dual alarm modes (audible and vibration) for flexible operation in various environments. The Bioteknix HM300 offers durable construction, long battery life, and reliable performance, ensuring consistent threat detection without interruption. Compact and portable, it's the perfect handheld security tool for both indoor and outdoor use.

Datasheet

share the website to

parameters

Product dimension 340mm x 140mm x 30mm
Package Size 360mm * 150mm* 50 mm
Working frequency About 20 KHz
Alarms sound (or vibration) and light
Power supply Standard 9V battery or rechargeable battery(optional)
Power 270mW
Battery 9V Alkaline Battery (Rechargeable Optional)
Operating Frequency < 50mA
Operating Voltage 7V – 9V
Operating Temperature -10℃ to to +65℃
Net Weight 180gm
Detection Range * Pin 35—70mm
* Type 64 pistol 220—250mm
* 6-inch dagger 200—240mm
* Diameter 20mm steel ball 150mm
* One ₹ coin 100—130 mm
Main features * Only ferrous metals can be detected, no gold and silver detection<
* Detection distance : Pistol: 90mm; Six Inches knife: 60m; Razor blades: 30mm; Pin: 10mm
* Self-calibrating : digital microprocessor technology eliminates the need for periodic sensitivity adjustments.
* Rugged, high-impact ABS case with reinforced coil compartment
* Large 10cm scan surface for quick, thorough scanning
* No tools required to change standard 9V battery. Optional rechargeable battery kit
* Sharp audible alarm and LED light vibration indicate the detection of metal
* Colour LED indication: Green LED power ON indicator; Red LED LOW BATTERY indicator; Red LED ALARM indicator; Green LED RECHARGING indicator
* Adjustable sensitivity knob
* Warranty: 12 months
Applications Airports and Seaports, subway, Railway, Bus Station, Electronic Factory, Post Office, Government Buildings, Exhibition hall, Embassy, Police Station, Court, Prisons/Jails, High-end occasion, Military Bases, Hospitals, Banks, Financial Institutions, Colleges and Schools, Hotels and Casinos, Power plants, Research Sites, Sports Stadiums, Public Transportation, Warehouses, Broadcast Studios, Museums, Night Clubs, Secret Meetings and VIP member Security, Gymnasium, Commercial buildings, Ships, Security checkpoints, office building
