KR503-M

MIFARE CARD READER

The Bioteknix KR503-M is a high-quality MIFARE card reader designed for secure and contactless access control using 13.56MHz smart card technology. Ideal for offices, universities, research labs, and secure facilities, it supports ISO14443A standard MIFARE cards for fast and reliable user authentication. The KR503-M features Wiegand 26/34 output, allowing smooth integration with a wide range of access control panels. Its IP65-rated waterproof and dustproof housing ensures durability and stable performance in both indoor and outdoor environments. With a sleek, compact design and fast read response, the Bioteknix KR503-M is a dependable and secure solution for modern access control systems.

Datasheet

share the website to

parameters

KR503M 13.56MHz Mifare card reader
Read Range Up to 5CM
Communication RS485
Reading Time (Card) ≤300ms
Power / Current DC 6-14V / Max.70mA
Input Port 2ea (External LED Control, External Buzzer Control)
Output Format 26bit Wiegand (default) / 34bit Wiegand (default)
LED Indicator 2 Color LED Indicators(Red and Green)
Beeper Yes
Operating Temperature 20° C to +65°C
Operating Temperature 20° C to +65°C
Operating Humidity 10% to 90% relative humidity non-condensing
Color Black
Dimension(WxHxT) 116 x 75 x 17.3mm
