MA500

ACCESS CONTROL TERMINAL

Bioteknix U460 is a fingerprint-based time attendance and access control system ideal for small to medium enterprises. It supports 2,200 fingerprint templates and stores up to 50,000 transaction logs. The device features a 500 DPI optical sensor with ≤1 second verification speed and a 32-bit high-speed processor for efficient performance. It has a 2.8-inch TFT color display, T9 input, and user-friendly interface. Communication options include TCP/IP, USB Host/Client, and optional Wi-Fi for real-time data transfer. U460 supports access control with relay outputs for electric locks, door sensors, exit buttons, alarms, and doorbells. Additional features include work code entry, short message display, scheduled bell, multi-language support, and a built-in web server. Designed for durability, it operates in temperatures from 0°C to 45°C with 20%–80% humidity. Compact and reliable, Bioteknix U460 offers a complete solution for biometric attendance and secure door access.

Datasheet

share the website to

parameters

Users 3000 Fingerprints
Card Capacity 30,000
Transaction 1,00,000 Logs
Sensor Optical Sensor with protective cover
Algorithm Version Finger V10.0
Communication TCP/IP, RS485
Access Control Interface Electric lock, Door sensor, Alarm, Exit button
Wiegand Signal Wiegand out
Power Supply 12V DC, 3A
Operating Temperature 0°C - 45°C
Operating Humidity 20% - 80%
Dimension(WxHxD) 83 x 127.5 x 74 mm
Ingress Protection Rate IP65
Features * Vandal resistant & IP65 waterproof, ideal for outdoor installation
* Combine master and slave system to secure the entrance and exit with dual biometric authentication simply and easily by RS485
* Support Anti-passback to maximize security level
* Configurable wiegand output to connect with most of the access control panel brands, easy replacement into existing systems
* Various types of alarm such as tamper alarm, door sensor alarm, duress alarm etc
* Optional proximity or mifare card reader
