The Bioteknix PSA02-02 Single Channel Loop Detector is a high-precision vehicle detection device designed for modern access control and traffic management systems. Ideal for use with boom barriers, automated gates, toll booths, and parking systems, the PSA02-02 ensures accurate detection of metallic vehicles passing over or stopped on an inductive loop. It features adjustable sensitivity levels, fast response time, and stable performance even in high-traffic environments. The compact design and easy DIN rail or surface mounting make installation simple. LED indicators allow for real-time status monitoring and diagnostics. Built for reliability, the PSA02-02 is compatible with a wide range of access control and gate automation systems. Whether for residential, commercial, or industrial use, the Bioteknix PSA02-02 Loop Detector provides dependable, single-channel vehicle detection for enhanced safety and control.
| Power Voltage | 220VAC±10% 50/60Hz 24VAC/DC±10% |
| Sensing range | 20~1500uH |
| Sensitivity | 0.02%~0.2% (4degress selections) |
| Reaction time | 100ms |
| Frequency | 2 degrees selectable |
| Output | 2 output relays (5A/AC230V), CH1:presencerelay CH2:pulse/faultrelay |
| Presence mode | Limited presence/ permanent presence |
| Indicator Power indicator | red LED , Status indicator: green LED |
| Internal protection | Isolation transformer, voltage Regulator tube, voltage Dependent resistor |
| Operating temp | -40℃~80℃ |
