S990

STANDALONE RFID TIME ATTENDANCE ACCESS CONTROL SYSTEM

The Bioteknix S990 Standalone RFID Time Attendance and Access Control System is a powerful solution for secure and efficient employee attendance tracking. Ideal for offices, schools, factories, and enterprises, it supports up to 30,000 RFID users and stores 100,000 attendance logs. With a fast verification time of under 1 second and a 2.8" TFT color screen, it ensures smooth and accurate check-ins. The device offers TCP/IP, RS232, RS485, and USB connectivity, plus optional Wi-Fi and GPRS for real-time data transfer. Designed for access control, it features Wiegand IN/OUT, door lock relay, fire alarm integration, and anti-passback. The Bioteknix S990 is easy to install, integrates with payroll software, and is perfect for businesses seeking a reliable, contactless RFID attendance system with access management. Upgrade your workforce management with Bioteknix's trusted technology.

Datasheet

share the website to

parameters

Display 2.8” TFT
Card Storage 30000
Card reader Yes
Transaction Capacity 100000
CPU 32 bit Microprocessor – 800Mhz
FAR <=0.0001% / FRR : <=1%
Identification speed < 1 sec
Algorithm Ver N/A
Keypad 4x4 with 5 Function Keys
Schedule Bell/Speaker Mini Speaker
COMMUNICATION * TCP/IP, RS232/485
* Standard features : work code,SMS,DLST, Self service query, Status Switch
POWER & ENVIRONMENT * Power Supply : DC 12V --- 1.5Amp
* Operating Temp : 0 °C - 45 °C
* Operating Humidity : 20% - 80%
* Dimension (in mm) : (L)210 x (W)157 x (H)40
ACCESS CONTROL * Wiegand : In & Out both 26 or 34 bit (With or without site code)
* Relay : 12 V relay for lock EM lock, Bolt Lock or Strike lock
* Support Fire Alarm : Yes
* Door Sensor : Yes
* Anti Passback : Yes
* Door Bell : Yes
EXIT READERS Support Exit Readers : KR500E / Exit Button, 101 HE
OPTIONAL * Battery : Yes
* Card Readers : Yes
* Communication : WiFi/GPRS
* Printer : Optional
COMPATIBILITY * Compatible with Multi Door controllers via weigand
* External Speaker output available (Optional)
* External Bulb output available (Optional)
COMPATIBLE SOFTWARE AND SDK * eTimetracklite desktop & web
* SDK for desktop applications
* Web based Device Manager/ePush server using Push data, Helps developers & integrators
* Supports 3rd Party Payroll/HRMS/ERP and Other applications
