SB-E315

Bioteknix SB-E315 Automatic Boom Barrier is a smart vehicle access control solution designed for high-traffic areas such as residential communities, commercial buildings, parking lots, and toll booths. Engineered with precision, the SB-E315 features a high-efficiency motor for smooth, stable, and rapid operation, ensuring minimal wear and long-lasting performance. The system supports adjustable boom lengths, auto-reverse on obstacle detection, and manual override during power failures. Built with a rugged, weatherproof body, it is ideal for outdoor installations and performs reliably in challenging environments. The SB-E315 integrates easily with RFID, ANPR, remote control, and access control systems, offering flexibility and advanced automation. Bioteknix ensures every barrier meets high standards of safety, reliability, and user convenience

Datasheet

share the website to

parameters

Product Size 168*168*1000mm (L*W*H)
Pass width 600 standard, 900mm Optional
Cabinet Material Stainless Steel 304 Grade, Round tube of thickness δ=2.2mm
Bar Material Transparent Acrylic Thickness δ=10mm
Movement Servo motor-based Swing Gate movement
Drive Unit 200W servo motor
Control Unit Servo control system
Power Supply 24V 500W
Power 50W
Pass rate 15-25 persons/minute
Temperature -20°~+70°
Humidity ≤90% No condensation
IP IP54
Environment Indoor and outdoor (outdoor with canopy)
