UHF1-TAG3

ULTRA HIGH FREQUENCY TAG

The Bioteknix UHF1-Tag3 is a high-performance UHF RFID tag designed for long-range vehicle identification and access control. Operating in the 840–960 MHz range and compliant with EPC Gen2 / ISO 18000-6C, it offers excellent compatibility with global RFID systems. Featuring the G2XM chip, it provides secure data storage with 96-bit EPC, user memory, and 32-bit access and kill passwords. With a read range of up to 10 meters when used with compatible UHF readers, it’s ideal for toll gates, parking systems, and fleet management. Its compact design (249 × 13.8 × 18 mm) allows easy installation on vehicle license plates. The Bioteknix UHF1-Tag3 is highly durable, built to withstand –30°C to 60°C, with a chip data retention life of up to 20 years. Whether used for secure parking access or automated vehicle tracking, this UHF tag delivers reliable, contactless performance in demanding environments.

Datasheet

share the website to

parameters

Working Frequency 840~960MHz/td>
Reading Distance Up to 10 meters for UHF1-10E and UHF1-10F (Determined by the environment and reader)
Protocol ISO / IEC18000-6C, EPC global Class 1 Gen 2
Memory Capacity 272 bits
Chip G2XM
Storage Structure 96bits, UID / TID: 64bits, User: 512bits, Access Password : 32bits, Kill Password: 32bit
Data Storage 20 years ( Only for chip )
Working Temperature -30℃ ~ 60℃
Storage Temperature -10℃ ~ 40℃
Storage Humidity 40%-70% RH
Dimension 249 * 13.8 * 18 ( mm ) ± 0.5 (mm)
Erase Endurance 10,000 times(Only for chips)
Environmental Requirements RoHS Certificate
Installation Fixed on the upper and lower edges of the license plate (Parking Applications)
Features * Embedded Assembly
* Metal Resistance
* High Chip Sensitivity
Typical Applications * Vehicle Management
* Highway (Bridge) Toll Collection Management
