UR10RW-F

UHF CARD ISSUER

The Bioteknix UR10RW-F is a compact and efficient UHF RFID desktop reader/writer designed for high-speed tag reading and encoding. Operating in the 860–960MHz UHF frequency band, it supports EPC Gen2 (ISO18000-6C) standards, ensuring compatibility with a wide range of UHF RFID tags. With USB interface for plug-and-play connectivity, the UR10RW-F is ideal for use in desktop applications like tag registration, inventory management, access control setup, and test environments. Its built-in antenna, sleek design, and user-friendly software make it suitable for retail, libraries, logistics, and office use. The Bioteknix UR10RW-F offers reliable performance, low power consumption, and an easy way to manage RFID data right from your workstation.

Datasheet

share the website to

parameters

Card Supporting UHF Tags, UHF Cards
Working Frequency 902MHz-928Mhz
Reading Distance 20~40CM valid distance (Determined by the environment & tags )
Protocol EPC global UHF Class1 Gen 2, ISO 18000-6C
Communication Interface USB analog keyboard output
Support Working Supporting American standard UHF reader
Working Voltage DC 5V (+ 4%)
Working Current 50~300mA
Working Temperature -10°C ~ +50°C
Storage Temperature -20°C ~ +80°C
Dimension 107*107*23mm(1mm) (wire length : 1500mm)
Features * Wiegand 26 output(Default); Wiegand 34 (Optional)
* With antenna, active card search mode
* USB data format output
* USB power supply, no drive
* Data Reception Time : less than 90ms
* Multi-system : Windows,Linux,Android,IOS
